Athena OS RDP Image

Athena OS container brings you to live a funny hacking experience in a containerized environment:

  • Select your favourite InfoSec role between Bug Bounty Hunter, Red Teamer, OSINT Specialist and much more
  • Play Hack The Box machines for improving your skills
  • Explore more than 2800+ hacking tools retrievable by Arch Linux and BlackArch repositories
  • Make your Capture The Flag or ethical hacking activity efficient

Click Docker icon above to explore Athena OS Docker containers!

Usage


Athena OS container has been developed in order to be run also by podman. The choice to use podman comes from its advantages over docker, one of most important: security.

According to your preference, install docker and docker-compose packages or podman package for your Linux environment.

In case you are using podman, edit /etc/containers/registries.conf and add:

[registries.search]
registries = ['docker.io']

in order to allow podman to search for images in Docker Hub.

Hack The Box API Token

Athena OS container allows you to learn and play on Hack The Box platform. It is possible to access to Hack The Box by using your App Token. Retrieve your App Token from the Hack The Box website in your Profile Settings.

Docker

You can run the container by docker-compose (recommended) or docker run.

docker-compose

The docker-compose.yml file should have the following content:

version: '3.4'
services:
athena-rdp:
image: athenaos/rdp
cap_add:
- cap_sys_admin
- ipc_lock
- net_admin
cgroup:
- host
devices:
- /dev/net/tun
ports:
- "127.0.0.1:23389:3389"
- "127.0.0.1:8022:22"
shm_size: '2gb'
sysctls:
- net.ipv6.conf.all.disable_ipv6=0
volumes:
- /sys/fs/cgroup:/sys/fs/cgroup
tmpfs:
- /run
- /tmp
restart: unless-stopped

Run the container by:

sudo docker-compose run athena-rdp

docker run

Terminal window
docker run -ti \
--name athena-rdp \
--cap-add CAP_SYS_ADMIN \
--cap-add IPC_LOCK \
--cap-add NET_ADMIN \
--cgroupns=host \
--device /dev/net/tun \
--shm-size 2G \
--sysctl net.ipv6.conf.all.disable_ipv6=0 \
--volume /sys/fs/cgroup:/sys/fs/cgroup \
--publish 23389:3389 \
--publish 8022:22 \
--restart unless-stopped \
docker.io/athenaos/rdp:latest

or

docker run -ti --name athena-rdp --cap-add CAP_SYS_ADMIN --cap-add IPC_LOCK --cap-add NET_ADMIN --cgroupns=host --device /dev/net/tun --shm-size 2G --sysctl net.ipv6.conf.all.disable_ipv6=0 --volume /sys/fs/cgroup:/sys/fs/cgroup --publish 23389:3389 --publish 8022:22 --restart unless-stopped docker.io/athenaos/rdp:latest

In case you exit the container and need to re-enter, run:

docker exec --user athena -ti athena-rdp /bin/zsh

In case the container is not running, run:

docker start athena-rdp

For stopping the container, run:

docker stop athena-rdp

For deleting the container, run:

docker container rm athena-rdp

Podman (Untested)

You can run the container by podman run.

podman run

Terminal window
podman run -ti \
--name athena-rdp \
--cap-add NET_RAW \
--cap-add NET_ADMIN \
--device /dev/net/tun \
--restart unless-stopped \
docker.io/athenaos/rdp:latest

or

podman run -ti --name athena-rdp --cap-add NET_RAW --cap-add NET_ADMIN --device /dev/net/tun --restart unless-stopped docker.io/athenaos/rdp:latest

Podman will automatically replicate /etc/hosts and /etc/hostname files of your host. For preventing this, add --no-hosts argument to the podman run command above.

In case you exit the container and need to re-enter, run:

podman exec --user athena -ti athena-rdp /bin/zsh

In case the container is not running, run:

podman start athena-rdp

For stopping the container, run:

podman stop athena-rdp

For deleting the container, run:

podman container rm athena-rdp

Default Credentials

athena:athena

Setting HTB API Token

Once you retrieved your HTB API Token from your Hack The Box website profile settings, you can set the HTB API Token in two ways:

  • By connecting by RDP to the GUI as explained in the next section, open terminal and run htb-update (or clicking HTB Update button in Athena Welcome)
  • If you don’t want to connect to the GUI environment, run the following commands:
    sudo mkdir -p /run/secrets
    sudo nano /run/secrets/htb-api
    <store your HTB API Token in htb-api file and save it>
    htb-play

Connect to the desktop by RDP

You should now be able to access your full-featured GNOME desktop using the RDP client of your choice. For example, using Remmina along with the install of freerdp package:

remmina -c rdp://127.0.0.1:23389

Remmina features

When you run Remmina, expand its window and on the left side press the Toggle dynamic resolution update icon button for automatically resizing the display.

For making the keyboard shortcut effective on the connected environment, on the left side press the Grab all keyboard events icon.

For copy and paste text from the host to the environment, copy a string, then, on the left side, click on Tools icon button and select Keystrokes and Send clipboard content as keystrokes.

Customizing and building the image

Clone this repository, edit Dockerfile and then run docker build as usual:

git clone https://github.com/Athena-OS/athena-rdp-docker.git
cd athena-rdp-docker
docker build --tag 'custom-athena-rdp:latest' .

Invalidating cache

Use --no-cache option:

docker build --tag 'custom-athena-rdp:latest' --no-cache .

Deployment on Apple M1/M2

Download Docker Desktop, open it and go to Settings, then enable it (use Rosetta for x86/amd64 emulation on Apple Silicon): image

In General, enable VirtueFS, then apply and restart: image

Open Terminal and pull Athena OS container by using docker pull --platform linux/amd64 athenaos/rdp:latest for Athena OS RDP container.

Once pulled, run:

docker run -ti --name athena-rdp --cap-add CAP_SYS_ADMIN --cap-add IPC_LOCK --cap-add NET_ADMIN --cgroupns=host --device /dev/net/tun --shm-size 2G --sysctl net.ipv6.conf.all.disable_ipv6=0 --volume /sys/fs/cgroup:/sys/fs/cgroup --publish 23389:3389 --publish 8022:22 --restart unless-stopped docker.io/athenaos/rdp:latest

Login by using athena:athena credential.

To connect by RDP session, use Microsoft Remote Desktop Service, type 127.0.0.1:23389: image

Save and connect to it.
